【Best Composable Solution】PCIe Gen4 GPU Chassis

Innovative PCIe switch box, Falcon,which used as a composable solution to provide a true PCIe resource pooling in a rack. Right size of GPU, NVMe, NIC, and FPGA for your traditional, cloud, and HPC applications.
Related Information: PCIe Gen4 External Box Provider、【Composable Pioneer】H3 Platform

GPU Expansion box Composable Solution

Falcon GPU Expansion Solution is the fastest way to enhance compute power of your existing system. Disaggregated GPU chassis with designated cooling solution eliminates any GPU overheat issues.
Falcon GPU Expansion Solution is PCIe Gen 4 based, readily compatible to latest GPUs coming from accelerator manufacturers like Nvidia® and AMD®. Our solution adapts PCIe interconnect technology to ensure both data rate and signal integrity. Rackmount GPU chassis significantly increase GPU densities of your applications.

GPU Expansion chassis parts

Main PCIe switch & PCIe slots

There are two Broadcom PEX88096 (PCIe Gen4 switch chipset, 96 PCIe lanes) in the chassis. Each fan-out into 6 PCIe x16 lanes, four lanes are dedicated to dual-width slots, one lane is for host adapter, and one lane is left configurable for single-width devices or extra host ports.

Host Adapter and Cables

We provide switch-based host adapter (Broadcom PEX88032, PCIe Gen4 switch chipset) that enables port bifurcation for the best flexibility. PCIe cable adopts SFF8644 connector, pin definition follow PCI-SIG standard.

Power Supply

Falcon GPU expansion chassis adopts Delta® server grade 1600W or 2000W PSU. Redundant PSU design ensures stable and sufficient power for multiple GPU at peak performance.

Cooling solution

6 x 12mm cooling fans, providing sufficient airflow to cool down the devices and the chassis, sustain your GPU performance under high stress conditions.

GPU Expansion chassis Applications

• Medical：
  Medical imaging can be accelerated by multi-GPUs. Higher quality image and faster visualizations in medical applications such as MRI and CT scans means more accurate and timely diagnosis. Falcon GPU Expansion Solution provides the simplest and the fastest way to increase computing power that backs up these medical imaging applications.
• Scientific Research：
  Labs and researchers often encounter large sets of data and complex algorithms to analyze it. Multi-GPU can speed up the data processing and analytics significantly. Falcon GPU Expansion Solution enables adding GPUs directly to any existing computing system to speed up any analytical process in labs without changing existing environments.
• 3D Design：
  GPU rendering has become a trend in design industry. Software such as Blender, V-ray and Maya now supports multi-GPU rendering for 3D designers to deliver higher quality creations. Falcon GPU Expansion Solution allows designers to leverage multiple GPUs easier not only for better rendering results but also for better rendering experience. Falcon GPU Expansion Solution is applicable to either rendering servers or workstations to enhance designers’/ studio productivity.
